Terrasol FoXta Pro v5.0.1 (Foundation Design)

Overview of Terrasol FoXta Professional

Terrasol FoXta Professional v5.0.1 is a specialized geotechnical engineering software developed by Terrasol, designed for the analysis of shallow foundations and the calculation of soil bearing capacity. This professional-grade tool is widely used by civil engineers, geotechnical consultants, and structural designers to validate foundation safety under various load and soil conditions.

Unlike generic structural analysis tools, FoXta Professional focuses exclusively on the soil-structure interaction, applying international standards (Eurocode 7, French standards DTU 13.12, and NF P 94-261) to determine the allowable bearing pressure of soils. This latest version, v5.0.1, introduces refined calculation modules and improved reporting features, making it a critical asset for foundation design workflows.

Key Features of Terrasol FoXta Professional v5.0.1

This software offers a comprehensive suite of features tailored for professional geotechnical analysis:

• Bearing Capacity Calculation – Computes ultimate and allowable bearing capacity using analytical methods (Terzaghi, Meyerhof, Hansen) and pressuremeter tests (PMT).

• Settlement Analysis – Estimates immediate and consolidation settlements under vertical and inclined loads.

• Multi-Layer Soil Profiling – Models up to 10 distinct soil layers with custom geotechnical parameters (cohesion, friction angle, unit weight).

• Foundation Type Support – Supports strip footings, square/rectangular isolated footings, and circular foundations.

• Load Combinations – Handles vertical, horizontal, and moment loads with customizable safety factors.

• EC7 Compliance – Includes partial factors for GEO and ULS design approaches per Eurocode 7.

• Graphical Outputs – Visualizes pressure distribution, settlement curves, and safety factor contours.

• Professional Report Generator – Exports detailed PDF or DOCX reports with tables, graphs, and calculation summaries.

What’s New in Terrasol FoXta Professional v5.0.1

Version 5.0.1 introduces several key improvements over previous releases:

• Enhanced PMT Module – Updated pressuremeter test interpretation aligned with NF P 94-261-1 (2021 revision).

• Improved Seismic Considerations – Added pseudo-static analysis for bearing capacity under earthquake loads.

• Faster Convergence Algorithms – Reduced computation time for multi-layer settlement models.

• Metric & Imperial Units – Seamless toggle between kN/m², t/m², and psi units.

• Excel Integration – Direct import of soil test data from .xlsx files without pre-formatting.

System Requirements

Before installing Terrasol FoXta Professional v5.0.1, ensure your system meets the following specifications:

Note: This software does not support macOS or Linux natively. Users on these platforms require a Windows virtual machine.

Installation Guide

Follow these steps to install Terrasol FoXta Professional v5.0.1 correctly:

1. Download the Installer – Obtain the official setup file from Terrasol’s authorized distribution channel.

2. Verify File Integrity – Check the SHA-256 hash against the value provided by Terrasol.

3. Run as Administrator – Right-click the .exe file and select “Run as administrator”.

4. Accept License Terms – Read and accept the End User License Agreement (EULA).

5. Choose Installation Path – Default: C:\Program Files\Terrasol\FoXta Pro\

6. Select Components – Choose full installation (including example projects and documentation).

7. Complete Installation – Allow the setup to configure environment variables.

8. Activate License – Enter your perpetual license key or subscription token provided upon purchase.

9. Restart System – Reboot to complete registry updates (recommended).

How to Use Terrasol FoXta Professional v5.0.1

This section provides a practical walkthrough for a typical foundation design task.

Step 1: Define Project Parameters

Launch the software and select New Project. Enter site name, project ID, and choose the design standard (e.g., Eurocode 7 – DA1).

Step 2: Input Soil Profile

Navigate to Soil Data → Add Layer. Input for each layer:

• Thickness (m)

• Soil type (clay, sand, silt)

• Bulk unit weight (kN/m³)

• Cohesion (kPa)

• Friction angle (°)

• Modulus of elasticity (MPa)

Step 3: Configure Foundation Geometry

Under Foundation Data, select:

• Foundation type (e.g., strip footing)

• Width (B) and length (L) in meters

• Embedment depth (Df)

• Inclination of base (if any)

Step 4: Apply Loads

In the Loading tab, enter:

• Vertical load (V) in kN/m or kN

• Horizontal load (H)

• Overturning moment (M)

Step 5: Run Analysis

Click Calculate Bearing Capacity. The engine performs:

1. Ultimate limit state (ULS) check

2. Serviceability limit state (SLS) settlement prediction

3. Safety factor calculation (target ≥ 3.0 for static loads)

Step 6: Review Results

Interpret the output table showing:

• q_ult (ultimate bearing capacity)

• q_net (net allowable pressure)

• Safety Factor (SF)

• Immediate settlement (mm)

Step 7: Generate Report

Select Export Report → choose PDF format. The report includes input parameters, intermediate calculations, and design conclusion.

Best Use Cases for Terrasol FoXta Professional

This software excels in specific geotechnical scenarios:

Advantages and Limitations

Advantages

• Standards compliance – Directly applies Eurocode 7 and French geotechnical rules.

• High precision – Validated against field plate load tests.

• Professional reporting – Audit-ready documentation.

• Lightweight – Low hardware requirements compared to full FEM suites.

• Dedicated support – Email and phone assistance from Terrasol engineers.

Limitations

• No 3D visualization – Limited to 2D cross-sections and graphs.

• No pile foundation module – For deep foundations, consider Terrasol’s FoXta Deep.

• Windows only – No native macOS/Linux version.

• Steep learning curve – Requires basic soil mechanics knowledge.

• Expensive license – Professional edition starts at €1,200/year.

Alternatives to Terrasol FoXta Professional

If FoXta Professional does not fit your workflow or budget, consider these alternatives:

Recommendation: For pure bearing capacity and settlement under EC7, FoXta Pro remains the most specialized tool. For complex soil-structure interaction, consider Plaxis.

Frequently Asked Questions

1. What is the primary difference between Terrasol FoXta Professional and standard FoXta?

Professional edition includes pressuremeter test (PMT) analysis, multi-layer settlements, and Eurocode 7 partial factors. The standard edition is limited to analytical methods on homogeneous soil.

2. Can I use FoXta Professional for seismic bearing capacity calculations?

Yes, version 5.0.1 introduces a pseudo-static module for earthquake loading. You must input horizontal seismic coefficient (k_h) based on local hazard maps.

3. Is there a free trial available for Terrasol FoXta Professional v5.0.1?

Terrasol offers a 14-day fully functional trial on request (requires business email and project description). No cracked or trial-reset tools are legitimately available.

4. Which file formats can I export from the report generator?

You can export to PDF, DOCX, RTF, and plain text (CSV). Graphs can be saved as PNG or SVG.

5. Does FoXta Professional support layered soils with groundwater?

Yes. You can define the water table level per layer. The software automatically applies buoyancy effects to unit weight below the water table.

6. Can I validate FoXta Pro results against hand calculations?

Absolutely. The software outputs intermediate equations. Most users validate using Terzaghi’s bearing capacity formula for simple cases before trusting automated results.

7. How often does Terrasol release updates?

Major versions (v5.x) are annual. Minor patches (v5.0.x) are released quarterly for bug fixes and standard updates. Update subscriptions are optional after the first year.

8. Does this software require an internet connection to run?

No. After online activation, FoXta Professional works fully offline. Only report sharing and updates need connectivity.

Final Thoughts

Terrasol FoXta Professional v5.0.1 stands as a reliable, standards-driven solution for geotechnical engineers who prioritize accuracy in bearing capacity analysis and settlement prediction. Its adherence to Eurocode 7 and French national appendices makes it particularly valuable for European infrastructure projects.

While the software lacks advanced 3D modeling and deep foundation modules, its focus on shallow foundations is unmatched in precision and ease of reporting. For engineering firms handling multiple small-to-medium projects, the time saved in automated EC7 checks and report generation justifies the license cost.
